Fiber4u Fiber Optic Adapters

Fiber optic adapters are essential components in fiber optic communication systems, designed to ensure reliable and efficient connections between different types of fiber connectors. Constructed from high-quality materials, these adapters offer low insertion loss and high connection reliability.

Features:

• Durability and Reliability: Fiber optic adapters are engineered for long-lasting and reliable performance.
• Various Connector Options: Compatible with different connector types such as SC, LC, ST, MTP/MPO to meet your network needs.
• Low Insertion Loss: High-quality connections ensure optimal signal transmission with minimal loss.
• Compact Design: Notable for its compact and ergonomic design, suitable for use in confined spaces.
• Industry Standards Compliance: Manufactured according to industry standards for reliable performance.

Popular Adapter Types:

1. SC (Subscriber Connector): One of the standard fiber optic connectors, providing high-performance connections.
2. LC (Lucent Connector): Known for its small size and high-density connection, especially favored in high-speed networks.
3. ST (Straight Tip): Provides mechanical connection and is used for a wide range of applications.
4. MTP/MPO (Multiple-Fiber Push-On/Pull-Off): A special connector type providing multiple fiber connections for high-speed data transmission.

Our fiber optic adapters provide an excellent connection solution for your fiber optic networks, offering various types to suit different needs.

Performance Specification:

• Sleeve Material: Ceramic, Phosphor Bronze
• Typical Insertion Loss, dB (IEC 61300-3-4): 0.10, 0.15
• Mating Durability (IEC 61300-2-2): ≤ 0.20 dB after 500 times
• Receptacle Retention Force (IEC 61754-4): 2N - 5.9N
• Operating Temperature (IEC 61300-2-22): -25°C to +70°C, 12 Cycles

Enhance Connectivity with Fiber4u Fiber Optic Adapters:

Ordering Information:

• SC, LC, FC, FS (FC Square), ST, E2 (E2000), MT (MTRJ)
• Hybrid Type: SS (SC-ST), LS (LC-ST), LF (LC-FC), LH (LC-SC)
• SX (Simplex), DX (Duplex), QD (Quad)
• LC DX SMA

Key Features:

• Precision Alignment Sleeve: Ensures excellent alignment for optimal fiber connectivity.
• Durable Performance: Exhibits minimal change (≤ 0.15 dB) after 500 mating cycles, guaranteeing long-lasting reliability.
• High-Performance and Reliable: Delivers consistently high performance and reliability for demanding fiber optic applications.
• Wide Operating Temperature Range: Functions seamlessly in temperatures ranging from -25°C to +70°C, ensuring reliability in diverse environments.
• Industry Compliance: Meets standards such as Telcordia GR-326-Core, IEC, and TIA for assured quality.
• High Precision Mechanical Dimensions: Ensures accuracy in mechanical dimensions for a secure and stable connection.
• Sleeve Options: Available with a choice of Ceramic or PB sleeves to suit specific application needs.
• Versatile Adapter Types: Offers Hybrid Adapters and Shutter Adapters for diverse connectivity requirements.
• Dustproof Cap: Equipped with a dustproof cap to protect the adapter and maintain cleanliness in challenging environments.

Applications:

• Telecommunications Networks: Fiber4u adapters deliver precision connections crucial for the reliable performance of telecommunications networks, ensuring seamless data transmission.
• Data Centers: Tailored for data centers, these adapters provide precise alignment and durable performance, supporting key applications in high-speed data environments.
• CATV Systems: Fiber4u adapters are well-suited for CATV systems, offering optimal connectivity for high-performance data and video transmission.
• Versatile Usage in Diverse Environments: With a wide operating temperature range, Fiber4u adapters are ideal for various applications across industries, ensuring precision connections in environments with temperature fluctuations.
